The HT-DT-461/481/551 is a desktop soldering robot family covering 300 x 300 mm to 500 x 500 mm travel with 4 or 5 axes. Central smoking exhaust, real-time temperature monitoring, CCD vision locating and a multi-feed solder wire module, with ±0.02 mm repeat accuracy and 110-123 kg machine weight.
| Model | HT-DT-461 |
| Dimension | L575 × W620 × H965 mm |
| Travel Range | X300 / Y300 / Z100 mm, R360° |
| Product Max. Size | 230 × 300 mm |
| Control Method | IPC |
| Drive Mode | Step Motor |
| Number of Axis | 4 (X / Y / Z / R) |
| Static Temperature | ±1 °C |
| Temperature Range | 50-500 / 250-500 °C |
| Maximum Load | 12 kg (standard) / 20 kg (optional) |
| Maximum Move Speed | 650 mm/s |
| Repeat Position Accuracy | ±0.02 mm |
| Solder Wire Diameter | Breaking 0.6-2.0 mm / Feeding 0.3-2.0 mm |
| Average Power Consumption | 220 V / 550 W |
| Power | 400 W core 580 W / 200 W core 480 W |
| Weight | 110 kg |
| Model | HT-DT-481 |
| Dimension | L775 × W745 × H965 mm |
| Travel Range | X500 / Y500 / Z100 mm, R360° |
| Product Max. Size | 430 × 500 mm |
| Control Method | IPC |
| Drive Mode | Step Motor |
| Number of Axis | 4 (X / Y / Z / R) |
| Static Temperature | ±1 °C |
| Temperature Range | 50-500 / 250-500 °C |
| Maximum Load | 12 kg (standard) / 20 kg (optional) |
| Maximum Move Speed | 650 mm/s |
| Repeat Position Accuracy | ±0.02 mm |
| Solder Wire Diameter | Breaking 0.6-2.0 mm / Feeding 0.3-2.0 mm |
| Average Power Consumption | 220 V / 550 W |
| Power | 400 W core 510 W / 200 W core 410 W |
| Weight | 115 kg |
| Model | HT-DT-551 |
| Dimension | L775 × W745 × H965 mm |
| Travel Range | X500 / Y500 / Z100 mm, R360° |
| Product Max. Size | 210 × 500 mm per fixture |
| Control Method | IPC |
| Drive Mode | Step Motor |
| Number of Axis | 5 (X / Y1 / Y2 / Z / R) |
| Static Temperature | ±1 °C |
| Temperature Range | 50-500 / 250-500 °C |
| Maximum Load | 12 kg (standard) / 20 kg (optional) |
| Maximum Move Speed | 650 mm/s |
| Repeat Position Accuracy | ±0.02 mm |
| Solder Wire Diameter | Breaking 0.6-2.0 mm / Feeding 0.3-2.0 mm |
| Average Power Consumption | 220 V / 700 W |
| Power | 400 W core 570 W / 200 W core 470 W |
| Weight | 123 kg |
